Image Sensor

1/3" CMOS

Effective Pixels

1280(H)×960(V), 1.3MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/50s~1/100000s

NTSC: 1/60s~1/100000s

Minimum Illumination

0.05Lux/F1.2 (Color), 0.005Lux/F1.2 (B/W)

S/N Ratio

More than 65dB

IR Distance

N/A

IR On/Off Control

N/A

IR LEDs

N/A

Lens

Lens Type

C/CS lens / Fixed iris

Mount Type

C/CS

Focal Length

N/A

Max Aperture

N/A

Angle of View

N/A

Focus Control

Auto / Manual

Close Focus Distance

N/A

Pan / Tilt / Rotation

Pan/Tilt/Rotation

N/A

Video

Resolution

720P (1280×720)

Frame Rate

25/30fps@720P

Video Output

1-channel BNC HDCVI high definition video output / CVBS video output (Can switch)

Day/Night

Auto (ICR) / Manual

OSD Menu

English

BLC Mode

BLC / HLC / DWDR

WDR

DWDR

Gain Control

AGC

Noise Reduction

2D

White Balance

Auto / Manual

Smart IR

N/A

Certifications

Certifications

CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface

Audio Interface

1-channel audio in

Alarm Interface

N/A

Eelectrical

Power Supply

DC 12V±25%

Power Consumption

Max 1W (12V DC, IR on)

Environmental

Operating Conditions

-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH

* Start up should be done at above -30°C (-22°F)

Storage Conditions

-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH

Ingress Protection &Vandal Resistance

N/A

Construction

Casing

Plastic

Dimensions

144.4mm×75.5mm×63.6mm (5.69"×2.97"×2.50")

Net Weight

0.23kg (0.51lb)

Gross Weight

0.34kg (0.75lb)
